CEWay™
-
Suppliers
DataSheet
General Description
CEWay™ Maximum Ratings
| Parameter | Sym | Min | Max | Units | Test Conditions |
| Supply Voltage | VDD- Vss | -0.3 | 7 | V | |
| DC Input Voltage | VIN | -0.3 | VDD +0.3 | V | |
| DC Input Current | IIN | -10 | +10 | mA | |
| Storage Temperature | TSTG | -40 | +125 | OC | |
| ESD Tolerance | 2 | kV |
CEWay™ Features
· CEBus power line Physical Layer
· Power line medium dependent Physical and Symbol Encoding Sublayers
· Proprietary DSP for superior signal Reception in noisy environments
· M8052 core microcontroller
· 4 SFRs for communication between PLSES and M8052
· Up to 64 KB of external data memory
· 256 bytes of internal data memory
· Up to 64 KB of external code memory (can be extended with bank switching)
· Three 16-bit timer/counters
· Full-duplex serial port
· 15 I/O pins
· 68-pin PLCC package
· Industrial operating temperature range
· Power line medium dependent Physical and Symbol Encoding Sublayers
· Proprietary DSP for superior signal Reception in noisy environments
· M8052 core microcontroller
· 4 SFRs for communication between PLSES and M8052
· Up to 64 KB of external data memory
· 256 bytes of internal data memory
· Up to 64 KB of external code memory (can be extended with bank switching)
· Three 16-bit timer/counters
· Full-duplex serial port
· 15 I/O pins
· 68-pin PLCC package
· Industrial operating temperature range
CEWay™ Connection Diagram
