CD74ACT08M, CD74ACT08M96, CD74ACT109E

Table of contents:
Info of CD74ACT08M
Info of CD74ACT08M96
Info of CD74ACT109E

CD74ACT08M, CD74ACT08M96, CD74ACT109E Selling Leads, Datasheet

MFG:Texas Instruments Category:Integrated Circuits (ICs) Package Cooled:SOP14 D/C:08+

CD74ACT08M, CD74ACT08M96, CD74ACT109E Datasheet download

Five Points

Part Number: CD74ACT08M

Category: Integrated Circuits (ICs)

MFG: Texas Instruments

Package Cooled: SOP14

D/C: 08+

Description: IC DUAL JK POS-EDG-TRG FF 16-DIP

Price Break

1
25
100
250
500
1000
5000

Unit Price

.60000
.45000
.33750
.24900
.21000
.19950
.19125

Extended Price

0.60
11.25
33.75
62.25
105.00
199.50
956.25

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

CD74ACT08M Parameters

Technical/Catalog Information	CD74ACT08M
Vendor	Texas Instruments
Category	Integrated Circuits (ICs)
Number of Circuits	4 - Quad
Package / Case	14-SOIC (3.9mm Width), 14-SOL
Logic Type	AND Gate
Packaging	Tube
Mounting Type	Surface Mount
Number of Inputs	2
Current - Output High, Low	24mA, 24mA
Supply Voltage	4.5 V ~ 5.5 V
Operating Temperature	-55°C ~ 125°C
Voltage - Supply	4.5 V ~ 5.5 V
Drawing Number	296; 4040047-3; D; 14
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CD74ACT08M CD74ACT08M 296 4253 5 ND 29642535ND 296-4253-5

CD74ACT08M96 Parameters

Technical/Catalog Information	CD74ACT08M96
Vendor	Texas Instruments (VA)
Category	Integrated Circuits (ICs)
Number of Circuits	4 - Quad
Package / Case	14-SOIC (3.9mm Width), 14-SOL
Logic Type	AND Gate
Packaging	Cut Tape (CT)
Mounting Type	Surface Mount
Number of Inputs	2
Current - Output High, Low	24mA, 24mA
Supply Voltage	4.5 V ~ 5.5 V
Operating Temperature	-55°C ~ 125°C
Voltage - Supply	4.5 V ~ 5.5 V
Drawing Number	296; 4040047-3; D; 14
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CD74ACT08M96 CD74ACT08M96 296 14489 1 ND 296144891ND 296-14489-1

CD74ACT109E Parameters

Technical/Catalog Information	CD74ACT109E
Vendor	Texas Instruments
Category	Integrated Circuits (ICs)
Mounting Type	Through Hole
Package / Case	16-DIP (300 mil)
Function	Set and Reset
Number of Bits per Element	1
Number of Elements	2 - Dual
Current - Output High, Low	24mA, 24mA
Output Type	Differential
Trigger Type	Positive Edge
Type	JK Type
Packaging	Tube
Operating Temperature	-55°C ~ 125°C
Delay Time - Propagation	2.6ns
Frequency - Clock	100MHz
Voltage - Supply	4.5 V ~ 5.5 V
Drawing Number	296; 4040049; N; 14, 16, 18, 20
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CD74ACT109E CD74ACT109E
