EEE-FC1A101AP, EEE-FC1A101P, EEE-FC1A102AP

Table of contents:
Info of EEE-FC1A101AP
Info of EEE-FC1A101P
Info of EEE-FC1A102AP

EEE-FC1A101AP, EEE-FC1A101P, EEE-FC1A102AP Selling Leads, Datasheet

MFG:Panasonic - ECG Category:Capacitors Package Cooled:06+ D/C:PANASONIC

EEE-FC1A101AP, EEE-FC1A101P, EEE-FC1A102AP Datasheet download

Five Points

Part Number: EEE-FC1A101AP

Category: Capacitors

MFG: Panasonic - ECG

Package Cooled: 06+

D/C: PANASONIC

Description: CAP ELECT 1000UF 10V FC SMD

Price Break

1000
5000
10000
25000

Unit Price

.17100
.16000
.14800
.13900

Extended Price

171.00
800.00
1480.00
3475.00

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

EEE-FC1A101AP Parameters

Technical/Catalog Information	EEE-FC1A101AP
Vendor	Panasonic - ECG
Category	Capacitors
Capacitance	100F
ESR (Equivalent Series Resistance)	-
Features	General Purpose
Lifetime @ Temp.	1000 Hrs @ 105°C
Maximum Temperature	-40°C ~ 105°C
Size / Dimension	0.315" Dia x 0.244" H (8.00mm x 6.20mm)
Lead Spacing	-
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Tape & Reel (TR)
Tolerance	±20%
Voltage Rating	10V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FC1A101AP EEEFC1A101AP PCE4338TR ND PCE4338TRND PCE4338TR

EEE-FC1A101P Parameters

Technical/Catalog Information	EEE-FC1A101P
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	100F
ESR (Equivalent Series Resistance)	-
Features	General Purpose
Lifetime @ Temp.	1000 Hrs @ 105°C
Maximum Temperature	-40°C ~ 105°C
Size / Dimension	0.315" Dia x 0.244" H (8.00mm x 6.20mm)
Lead Spacing	-
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	10V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FC1A101P EEEFC1A101P PCE3989DKR ND PCE3989DKRND PCE3989DKR

EEE-FC1A102AP Parameters

Technical/Catalog Information	EEE-FC1A102AP
Vendor	Panasonic - ECG
Category	Capacitors
Capacitance	1000F
ESR (Equivalent Series Resistance)	-
Features	General Purpose
Lifetime @ Temp.	1000 Hrs @ 105°C
Maximum Temperature	-40°C ~ 105°C
Size / Dimension	0.394" Dia x 0.402" H (10.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Tape & Reel (TR)
Tolerance	±20%
Voltage Rating	10V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FC1A102AP EEEFC1A102AP PCE4342TR ND PCE4342TRND PCE4342TR
