EEE-FP0J471AP, EEE-FP1A102AP, EEE-FP1A151AP

Table of contents:
Info of EEE-FP0J471AP
Info of EEE-FP1A102AP
Info of EEE-FP1A151AP

EEE-FP0J471AP, EEE-FP1A102AP, EEE-FP1A151AP Selling Leads, Datasheet

MFG:Panasonic - ECG (VA) Category:Capacitors Package Cooled:SMD D/C:09+

EEE-FP0J471AP, EEE-FP1A102AP, EEE-FP1A151AP Datasheet download

Five Points

Part Number: EEE-FP0J471AP

Category: Capacitors

MFG: Panasonic - ECG (VA)

Package Cooled: SMD

D/C: 09+

Description: CAP 150UF 10V ELECT FP SMD

Price Break

5
10
25
100

Unit Price

.79600
.65500
.60840
.56160

Extended Price

3.98
6.55
15.21
56.16

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

EEE-FP0J471AP Parameters

Technical/Catalog Information	EEE-FP0J471AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	470F
ESR (Equivalent Series Resistance)	80.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.315" Dia x 0.402" H (8.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	6.3V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP0J471AP EEEFP0J471AP PCE4518DKR ND PCE4518DKRND PCE4518DKR

EEE-FP1A102AP Parameters

Technical/Catalog Information	EEE-FP1A102AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	1000F
ESR (Equivalent Series Resistance)	60.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.394" Dia x 0.402" H (10.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	10V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1A102AP EEEFP1A102AP PCE4434DKR ND PCE4434DKRND PCE4434DKR

EEE-FP1A151AP Parameters

Technical/Catalog Information	EEE-FP1A151AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	150F
ESR (Equivalent Series Resistance)	260.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.248" Dia x 0.228" H (6.30mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	10V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1A151AP EEEFP1A151AP PCE4522DKR ND PCE4522DKRND PCE4522DKR
