EEE-FP1C680AP, EEE-FP1C681AP, EEE-FP1E100AR

Table of contents:
Info of EEE-FP1C680AP
Info of EEE-FP1C681AP
Info of EEE-FP1E100AR

EEE-FP1C680AP, EEE-FP1C681AP, EEE-FP1E100AR Selling Leads, Datasheet

MFG:Panasonic - ECG (VA) Category:Capacitors Package Cooled:SMD D/C:09+

EEE-FP1C680AP, EEE-FP1C681AP, EEE-FP1E100AR Datasheet download

Five Points

Part Number: EEE-FP1C680AP

Category: Capacitors

MFG: Panasonic - ECG (VA)

Package Cooled: SMD

D/C: 09+

Description: CAP 10UF 25V ELECT FP SMD

Price Break

5
10
25
100
500

Unit Price

.37600
.30900
.28680
.26490
.22076

Extended Price

1.88
3.09
7.17
26.49
110.38

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

EEE-FP1C680AP Parameters

Technical/Catalog Information	EEE-FP1C680AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	68F
ESR (Equivalent Series Resistance)	260.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.248" Dia x 0.228" H (6.30mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1C680AP EEEFP1C680AP PCE4532DKR ND PCE4532DKRND PCE4532DKR

EEE-FP1C681AP Parameters

Technical/Catalog Information	EEE-FP1C681AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	680F
ESR (Equivalent Series Resistance)	60.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.394" Dia x 0.402" H (10.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1C681AP EEEFP1C681AP PCE4437DKR ND PCE4437DKRND PCE4437DKR

EEE-FP1E100AR Parameters

Technical/Catalog Information	EEE-FP1E100AR
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	10F
ESR (Equivalent Series Resistance)	850.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.158" Dia x 0.228" H (4.00mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.169" L x 0.169" W (4.30mm x 4.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	25V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1E100AR EEEFP1E100AR PCE4539DKR ND PCE4539DKRND PCE4539DKR
