EEE-FP1E331AP, EEE-FP1E470AP, EEE-FP1E471AP

Table of contents:
Info of EEE-FP1E331AP
Info of EEE-FP1E470AP
Info of EEE-FP1E471AP

EEE-FP1E331AP, EEE-FP1E470AP, EEE-FP1E471AP Selling Leads, Datasheet

MFG:Panasonic - ECG (VA) Category:Capacitors Package Cooled:SMD D/C:07+08+

EEE-FP1E331AP, EEE-FP1E470AP, EEE-FP1E471AP Datasheet download

Five Points

Part Number: EEE-FP1E331AP

Category: Capacitors

MFG: Panasonic - ECG (VA)

Package Cooled: SMD

D/C: 07+08+

Description: CAP 470UF 25V ELECT FP SMD

Price Break

5
10
25
100

Unit Price

.79000
.65100
.60440
.55800

Extended Price

3.95
6.51
15.11
55.80

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

EEE-FP1E331AP Parameters

Technical/Catalog Information	EEE-FP1E331AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	330F
ESR (Equivalent Series Resistance)	80.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.315" Dia x 0.402" H (8.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	25V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1E331AP EEEFP1E331AP PCE4439DKR ND PCE4439DKRND PCE4439DKR

EEE-FP1E470AP Parameters

Technical/Catalog Information	EEE-FP1E470AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	47F
ESR (Equivalent Series Resistance)	260.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.248" Dia x 0.228" H (6.30mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	25V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1E470AP EEEFP1E470AP PCE4543DKR ND PCE4543DKRND PCE4543DKR

EEE-FP1E471AP Parameters

Technical/Catalog Information	EEE-FP1E471AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	470F
ESR (Equivalent Series Resistance)	60.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.394" Dia x 0.402" H (10.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	25V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1E471AP EEEFP1E471AP PCE4440DKR ND PCE4440DKRND PCE4440DKR
