EEE-FP1V221AP, EEE-FP1V330AP, EEE-FP1V331AP

Table of contents:
Info of EEE-FP1V221AP
Info of EEE-FP1V330AP
Info of EEE-FP1V331AP

EEE-FP1V221AP, EEE-FP1V330AP, EEE-FP1V331AP Selling Leads, Datasheet

MFG:Panasonic - ECG (VA) Category:Capacitors Package Cooled:2009+ROHS D/C:40000

EEE-FP1V221AP, EEE-FP1V330AP, EEE-FP1V331AP Datasheet download

Five Points

Part Number: EEE-FP1V221AP

Category: Capacitors

MFG: Panasonic - ECG (VA)

Package Cooled: 2009+ROHS

D/C: 40000

Description: CAP 330UF 35V ELECT FP SMD

Price Break

5
10
25
100

Unit Price

.79000
.65100
.60440
.55800

Extended Price

3.95
6.51
15.11
55.80

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

EEE-FP1V221AP Parameters

Technical/Catalog Information	EEE-FP1V221AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	220F
ESR (Equivalent Series Resistance)	80.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.315" Dia x 0.402" H (8.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.327" L x 0.327" W (8.30mm x 8.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	35V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1V221AP EEEFP1V221AP PCE4444DKR ND PCE4444DKRND PCE4444DKR

EEE-FP1V330AP Parameters

Technical/Catalog Information	EEE-FP1V330AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	33F
ESR (Equivalent Series Resistance)	260.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.248" Dia x 0.228" H (6.30mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	35V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1V330AP EEEFP1V330AP PCE4551DKR ND PCE4551DKRND PCE4551DKR

EEE-FP1V331AP Parameters

Technical/Catalog Information	EEE-FP1V331AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	330F
ESR (Equivalent Series Resistance)	60.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.394" Dia x 0.402" H (10.00mm x 10.20mm)
Lead Spacing	-
Surface Mount Land Size	0.406" L x 0.406" W (10.30mm x 10.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	35V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1V331AP EEEFP1V331AP PCE4445DKR ND PCE4445DKRND PCE4445DKR
