EEE-FPA330UAR, EEE-FPC101XAP, EEE-FPC151XAP

Table of contents:
Info of EEE-FPA330UAR
Info of EEE-FPC101XAP
Info of EEE-FPC151XAP

EEE-FPA330UAR, EEE-FPC101XAP, EEE-FPC151XAP Selling Leads, Datasheet

MFG:Panasonic - ECG (VA) Category:Capacitors Package Cooled:SMD D/C:09+

EEE-FPA330UAR, EEE-FPC101XAP, EEE-FPC151XAP Datasheet download

Five Points

Part Number: EEE-FPA330UAR

Category: Capacitors

MFG: Panasonic - ECG (VA)

Package Cooled: SMD

D/C: 09+

Description: CAP 150UF 16V ELECT FP SMD

Price Break

5
10
25
100
500

Unit Price

.28000
.23100
.21440
.19800
.16500

Extended Price

1.40
2.31
5.36
19.80
82.50

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

EEE-FPA330UAR Parameters

Technical/Catalog Information	EEE-FPA330UAR
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	33F
ESR (Equivalent Series Resistance)	850.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.158" Dia x 0.228" H (4.00mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.169" L x 0.169" W (4.30mm x 4.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	10V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FPA330UAR EEEFPA330UAR PCE4521DKR ND PCE4521DKRND PCE4521DKR

EEE-FPC101XAP Parameters

Technical/Catalog Information	EEE-FPC101XAP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	100F
ESR (Equivalent Series Resistance)	160.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.248" Dia x 0.303" H (6.30mm x 7.70mm)
Lead Spacing	-
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FPC101XAP EEEFPC101XAP PCE4534DKR ND PCE4534DKRND PCE4534DKR

EEE-FPC151XAP Parameters

Technical/Catalog Information	EEE-FPC151XAP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	150F
ESR (Equivalent Series Resistance)	160.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.248" Dia x 0.303" H (6.30mm x 7.70mm)
Lead Spacing	-
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FPC151XAP EEEFPC151XAP PCE4535DKR ND PCE4535DKRND PCE4535DKR
