MFG:Analog Devices Inc Category:Programmers, Development Systems Package Cooled:EB D/C:2010+
EVAL-ADXL330Z, EVAL-ADXL345Z, EVAL-ADXRS610Z Datasheet download
Category: Programmers, Development Systems
MFG: Analog Devices Inc
Package Cooled: EB
D/C: 2010+
Description: BOARD W/ADXRS610BBGZ
Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.
TOP
PDF/DataSheet Download
Datasheet: EVAL-ADXL330Z
File Size: 64830 KB
Manufacturer:
Download : Click here to Download
PDF/DataSheet Download
Datasheet: EVA9224RS28
File Size: 266805 KB
Manufacturer: ANADIGICS [ANADIGICS, Inc]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: EVA9224RS28
File Size: 266805 KB
Manufacturer: ANADIGICS [ANADIGICS, Inc]
Download : Click here to Download
| Technical/Catalog Information | EVAL-ADXL330Z |
| Vendor | Analog Devices Inc |
| Category | Programmers, Development Systems |
| Sensor Type | Accelerometer, 3 Axis |
| Sensing Range | ±3.6g |
| Sensitivity | 300mV/g |
| Interface | Analog |
| Voltage - Supply | 1.8 V ~ 3.6 V |
| Supplied Contents | Board |
| Utilized IC / Part | ADXL330 |
| Embedded | No |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | EVAL ADXL330Z EVALADXL330Z |
The EVAL-ADXL330Z is a simple evaluation board that allows quick evaluation of the performance of the ADXL330 dual-axis accelerometer. The EVAL-ADXL330Z has a 5-pin, 0.1 inch spaced header for access to all power and signal lines that the user can attach to a prototyping board (breadboard) or wire using a standard plug. Four holes are provided for mechanical attachment of the EVAL-ADXL330Z to the application.
The EVAL-ADXL330Z is 20 mm × 20 mm with mounting holes set 15 mm × 15 mm at the corners of the PCB.
| Technical/Catalog Information | EVAL-ADXL345Z |
| Vendor | Analog Devices Inc |
| Category | Programmers, Development Systems |
| Sensor Type | Accelerometer, 3 Axis |
| Sensing Range | ±2g, 4g, 8g, 16g |
| Sensitivity | 256 LSB/g |
| Interface | I²C, SPI |
| Voltage - Supply | 1.8 V ~ 3.6 V |
| Supplied Contents | Board |
| Utilized IC / Part | ADXL345 |
| Embedded | No |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | EVAL ADXL345Z EVALADXL345Z |
| Technical/Catalog Information | EVAL-ADXRS610Z |
| Vendor | Analog Devices Inc |
| Category | Programmers, Development Systems |
| Sensor Type | Gyroscope, 1 Axis (Yaw Rate) |
| Sensing Range | ±300°/sec |
| Sensitivity | 6 mV/°/s |
| Interface | Analog |
| Voltage - Supply | 4.75 V ~ 5.25 V |
| Supplied Contents | Board |
| Utilized IC / Part | ADXRS610 |
| Embedded | No |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | EVAL ADXRS610Z EVALADXRS610Z |
