MFG:Fairchild Semiconductor Category:Integrated Circuits (ICs) Package Cooled:DFN-10 D/C:2010+
FSA2269, FSA2269L10X, FSA2269TS Datasheet download
Category: Integrated Circuits (ICs)
MFG: Fairchild Semiconductor
Package Cooled: DFN-10
D/C: 2010+
Description: IC SWITCH ANLG DUAL SPDT 10MCRPK
Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.
TOP
PDF/DataSheet Download
Datasheet: FSA2269L10X
File Size: 99971 KB
Manufacturer: FAIRCHILD [Fairchild Semiconductor]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: FSA2269L10X
File Size: 99971 KB
Manufacturer: FAIRCHILD [Fairchild Semiconductor]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: FSA1156
File Size: 498532 KB
Manufacturer: FAIRCHILD [Fairchild Semiconductor]
Download : Click here to Download
The FSA2269 is a high-performance, dual Single-Pole Double-Throw (SPDT) analog switch with negative swing audio capability. The FSA2269 features ultra-low RON of 0.4 (typical) at 3.0V VCC. The FSA2269 operates over a wide VCC range of 1.65V to 4.3V, is fabricated with submicron CMOS technology to achieve fast switching speeds, and is designed for break-before-make operation. The select input is TTL-level compatible.
The FSA2269 features very low quiescent current even when the control voltage is lower than the VCC supply. This feature suits mobile handset applications by allowing direct interface with baseband processor general-purpose I/Os with minimal battery consumption.
The FSA2269TS includes termination resistors that improve noise immunity during overshoot excursions, off-isolation coupling, or "pop-minimization."
| Product | Product status | Eco Status | Pricing* | Package type | Leads | Packing method | Package Drawing | Package Marking Convention** |
|---|---|---|---|---|---|---|---|---|
| FSA2269L10X | Full Production | RoHS Compliant | $0.40 | MicroPak | 10 | TAPE REEL | Line 1: HL | |
| FSA2269UMX | Full Production | Green | $0.40 | UMLP | 10 | TAPE REEL | Line 1: HP |
| * Fairchild 1,000 piece Budgetary Pricing |
| ** A sample button will appear if the part is available through Fairchild's on-line samples program. If there is no sample button, please contact a Fairchild distributor to obtain samples |
Package marking information for product FSA2269 is available. Click here for more information . |
| Technical/Catalog Information | FSA2269L10X |
| Vendor | Fairchild Semiconductor |
| Category | Integrated Circuits (ICs) |
| Type | Switch |
| Voltage Supply Source | Single Supply |
| Voltage - Supply, Single/Dual (±) | 1.65 V ~ 4.3 V |
| Circuit | 2 x SPDT |
| On-State Resistance | 250 mOhm |
| Mounting Type | Surface Mount |
| Package / Case | 10-MicroPak? |
| Packaging | Tape & Reel (TR) |
| Current - Supply | - |
| Operating Temperature | - |
| Function | Switch |
| Drawing Number | * |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | FSA2269L10X FSA2269L10X FSA2269L10XTR ND FSA2269L10XTRND FSA2269L10XTR |
Double-Throw (SPDT) analog switch with negative swing audio capability. The FSA2269 features ultra-low RON of 0.4O (typical) at 3.0V VCC. The FSA2269 operates over a wide VCC range of 1.65V to 4.3V, is fabricated with submicron CMOS technology to achieve fast switching speeds, and is designed for break-before-make operation. The select input is TTL-level compatible.
The FSA2269 features very low quiescent current even when the control voltage is lower than the VCC supply. This feature suits mobile handset applications by allowing direct interface with baseband processor general-purpose I/Os with minimal battery consumption.
The FSA2269TS includes termination resistors that improve noise immunity during overshoot excursions, off-isolation coupling, or ?pop-minimization.?
| Product | Product status | Eco Status | Pricing* | Package type | Leads | Packing method | Package Drawing | Package Marking Convention** |
|---|---|---|---|---|---|---|---|---|
| FSA2269TSL10X | Full Production | RoHS Compliant | $0.386 | MicroPak | 10 | TAPE REEL | Line 1: HU | |
| FSA2269TSUMX | Full Production | Green | $0.386 | UMLP | 10 | TAPE REEL | Line 1: HT |
| * Fairchild 1,000 piece Budgetary Pricing |
| ** A sample button will appear if the part is available through Fairchild's on-line samples program. If there is no sample button, please contact a Fairchild distributor to obtain samples |
Package marking information for product FSA2269TS is available. Click here for more information . |
