0.236" L x 0.236" W x 0.118" H (6.00mm x 6.00mm x 3.00mm)
Packaging
Digi-Reel?
Type
Ferrite Core
Current
920mA
Mounting Type
Surface Mount
Q @ Freq
-
Self Resonant Freq
-
DC Resistance (DCR)
355.0 mOhm Max
Shielding
Shielded
Applications
General Purpose
Lead Free Status
Lead Free
RoHS Status
RoHS Compliant
Other Names
SD6030 680 R SD6030680R 513 1479 6 ND 51314796ND 513-1479-6
SD603C Features
High power FAST recovery diode series 1.0 to 2.0 µs recovery time High voltage ratings up to 2200V High current capability Optimized turn on and turn off characteristics Low forward recovery Fast and soft reverse recovery Press-puk encapsulation Case style conform to JEDEC B-43 Maximum junction temperature 125°C
SD603C Typical Application
Snubber diode for GTO High voltage free-wheeling diode Fast recovery rectifier applications
