MFG:International Rectifier Category:Discrete Semiconductor Products Package Cooled: I R D/C:TO:220
IRG4BC10U, IRG4BC15UD-SPBF, IRG4BC15UD-STRL Datasheet download
Category: Discrete Semiconductor Products
MFG: International Rectifier
Package Cooled: I R
D/C: TO:220
Description: IGBT N-CH W/DIO 600V 14A D2PAK
Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.
TOP
PDF/DataSheet Download
Datasheet: IRG4BC10UD
File Size: 189181 KB
Manufacturer: IRF [International Rectifier]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: IRG4BAC50S
File Size: 138592 KB
Manufacturer:
Download : Click here to Download
PDF/DataSheet Download
Datasheet: IRG4BAC50S
File Size: 138592 KB
Manufacturer:
Download : Click here to Download
| Technical/Catalog Information | IRG4BC10U |
| Vendor | International Rectifier |
| Category | Discrete Semiconductor Products |
| Input Type | Standard |
| Voltage - Collector Emitter Breakdown (Max) | 600V |
| Current - Collector (Ic) (Max) | 8.5A |
| Vce(on) (Max) @ Vge, Ic | 2.6V @ 15V, 5A |
| Power - Max | 38W |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 (Straight Leads) |
| Packaging | Tube |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | IRG4BC10U IRG4BC10U |
| Technical/Catalog Information | IRG4BC15UD-SPBF |
| Vendor | International Rectifier |
| Category | Discrete Semiconductor Products |
| Input Type | Standard |
| Voltage - Collector Emitter Breakdown (Max) | 600V |
| Current - Collector (Ic) (Max) | 14A |
| Vce(on) (Max) @ Vge, Ic | 2.4V @ 15V, 7.8A |
| Power - Max | 49W |
| Mounting Type | Surface Mount |
| Package / Case | D²Pak, TO-263 (2 leads + tab) |
| Packaging | Tube |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | IRG4BC15UD SPBF IRG4BC15UDSPBF |
The IRG4BC15UD-SPbF has the following features including UltraFast: Optimized for high frequencies from10 to 30 kHz in hard switching;IGBT Co-packaged with ultra-soft-recovery antiparallel diode;Industry standard D2Pak & TO-262 packages;Lead-Free.
