S4558P, S4558T, S4560

Table of contents:
Info of S4558P
Info of S4558T
Info of S4560

S4558P, S4558T, S4560 Selling Leads, Datasheet

MFG:AUK Package Cooled:DIP8 D/C:04+

S4558P, S4558T, S4560 Datasheet download

Five Points

Part Number: S4558P

MFG: AUK

Package Cooled: DIP8

D/C: 04+

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

S4558P Maximum Ratings

Characteristic	Symbol	Ratings	Unit
Supply voltage	V_CC	36 or ±18	V
Differential input voltage	V_IND	30	V
Input voltage	V_IN	±15	V
Power Dissipation	P_D	500	mW
Operating temperature	T_opr	-40 ~ +85
Storage temperature	T_stg	-55 ~ +125

S4558P Features

• Power consumption as small as about 50mW (typ.)
• Built-in output short-circuit protecting circuit.
• Internal phase consumption type.
• No latch-up
• Wide same phase mode and differential voltage ranges
• High gain. low noise

S4558P Typical Application

• Active filters
• Audio amplifiers
• VCOs
• Other electronic circuits

S4560 General Description

The S4560 is dual operational amplifiers which achieve approximately twice the high output current of the S4560, as well as featuring a higher slew rate of 4V/us, a gain band width of 10MHz, and an improved frequency characteristic.

S4560 Maximum Ratings

Characteristic	Symbol	Ratings	Unit
Supply voltage	V_CC	±18	V
Differential input voltage	V_ID	±30	V
Input voltage	V_IC	-Vcc~Vcc	V
Power Dissipation	P_D^*	550	mW
Operating temperature	T_opr	-40 ~ +85
Storage temperature	T_stg	-55 ~ +125

* Refer to Pd characteristics diagram. The values for the S4560 are those when it is mounted on a glass epoxy
PCB(50 *50 *1.6 ).

S4560 Features

• Built-in output short-circuit protection circuit.
• Internal phase correction.
• No latch-up
• Wide same phase mode and differential voltage ranges
• High gain. low noise

S4560 Typical Application

• Active filters
• Audio amplifiers
• VCOs
• Other electronic circuits

S4560 Connection Diagram
