VAT1-S12-D15-SMT, VAT1-S12-D5-SMT, VAT1-S24-D12-SMT

Table of contents:
Info of VAT1-S12-D15-SMT
Info of VAT1-S12-D5-SMT
Info of VAT1-S24-D12-SMT

VAT1-S12-D15-SMT, VAT1-S12-D5-SMT, VAT1-S24-D12-SMT Selling Leads, Datasheet

MFG:CUI Inc Category:Power Supplies D/C:08+/09+

VAT1-S12-D15-SMT, VAT1-S12-D5-SMT, VAT1-S24-D12-SMT Datasheet download

Five Points

Part Number: VAT1-S12-D15-SMT

Category: Power Supplies

MFG: CUI Inc

Package Cooled:

D/C: 08+/09+

Description: CONVERTER DC/DC +/-12V OUT 1W

Price Break

500
2500
5000
12500
25000

Unit Price

4.17000
3.75300
3.61400
3.47500
3.33600

Extended Price

2085.00
9382.50
18070.00
43437.50
83400.00

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

VAT1-S12-D15-SMT Parameters

Technical/Catalog Information	VAT1-S12-D15-SMT
Vendor	CUI Inc
Category	Power Supplies
Voltage - Input	10.8 ~ 13.2VDC
Output	±15V
Power (Watts)	1W
Number of Outputs	2
1st Output	15 VDC @ 33mA
2nd Output	-15 VDC @ 33mA
3rd Output	-
4th Output	-
Type	Isolated
Mounting Type	Surface Mount
Packaging	Tape & Reel (TR)
Package / Case	10-DIP Module
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	VAT1 S12 D15 SMT VAT1S12D15SMT 102 1390 2 ND 10213902ND 102-1390-2

VAT1-S12-D5-SMT Parameters

Technical/Catalog Information	VAT1-S12-D5-SMT
Vendor	CUI Inc (VA)
Category	Power Supplies
Voltage - Input	10.8 ~ 13.2VDC
Output	±5V
Power (Watts)	1W
Number of Outputs	2
1st Output	5 VDC @ 100mA
2nd Output	-5 VDC @ 100mA
3rd Output	-
4th Output	-
Type	Isolated
Mounting Type	Surface Mount
Packaging	Cut Tape (CT)
Package / Case	10-DIP Module
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	VAT1 S12 D5 SMT VAT1S12D5SMT 102 1388 1 ND 10213881ND 102-1388-1

VAT1-S24-D12-SMT Parameters

Technical/Catalog Information	VAT1-S24-D12-SMT
Vendor	CUI Inc
Category	Power Supplies
Voltage - Input	21.6 ~ 26.4V
Output	±12V
Power (Watts)	1W
Number of Outputs	2
1st Output	12 VDC @ 42mA
2nd Output	-12 VDC @ 42mA
3rd Output	-
4th Output	-
Type	Isolated
Mounting Type	Surface Mount
Packaging	Tape & Reel (TR)
Package / Case	10-DIP Module
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	VAT1 S24 D12 SMT VAT1S24D12SMT 102 1392 2 ND 10213922ND 102-1392-2
