The IR2114/21141/2214/IR22141 gate driver family is suited to drive a single half bridge in power switching applications. The high gate driving capability (2A source, 3A sink) and the low quiescent current enable bootstrap supply techniques in medium power systems. These drivers feature full short circuit protection by means of the power transistor desaturation detection and manages all the half-bridge faults by turning off smoothly the desaturated transistor through the dedicated soft shut down pin, therefore preventing over-voltages and reducing EM emissions. In multi-phase system IR2114/21141/2214/IR22141 drivers communicate using a dedicated local network (SY_FLT and FAULT/SD signals) to properly manage phase-to-phase short circuits. The system controller may force shutdown or read device fault state through the 3.3 V compatible CMOS I/O pin (FAULT/SD). To improve the signal immunity from DC-bus noise, the control and power ground use dedicated pins enabling low-side emitter current sensing as well. Undervoltage conditions in floating and low voltage circuits are managed independently.
IR21141SS Maximum Ratings
Symbol
Definition
Min.
Max.
Units
VS
High side offset voltage
VB - 25
VB + 0.3
V
VB
High side floating supply voltage
(IR2114 or IR21141)
-0.3
625
(IR2214 or IR22141)
-0.3
1225
VHO
High side floating output voltage (HOP, HON and SSDH)
VS - 0.3
VB + 0.3
VCC
Low side and logic fixed supply voltage
-0.3
25
COM
Power ground
VCC - 25
VCC + 0.3
VLO
Low side output voltage (LOP, LON and SSDL)
VCOM -0.3
VCC + 0.3
VIN
Logic input voltage (HIN, LIN and FLT_CLR)
VSS -0.3
VCC + 0.3
VFLT
FAULT input/output voltage (FAULT/SD and SY_FLT)
VSS -0.3
VCC + 0.3
VDSH
High side DS input voltage
VS -3
VB + 0.3
VDSL
Low side DS input voltage
VCOM -3
VCC + 0.3
dVs/dt
Allowable offset voltage slew rate
-
50
V/ns
PD
Package power dissipation @ TA +25
-
1.5
W
RthJA
Thermal resistance, junction to ambient
-
65
/W
TJ
Junction temperature
-
125
TS
Storage temperature
-55
150
TL
Lead temperature (soldering, 10 seconds)
-
300
IR21141SS Features
• Floating channel up to +600 or +1200V • Soft over-current shutdown • Synchronization signal to synchronize shut down with the other phases • Integrated desaturation detection circuit • Two stage turn on output for di/dt control • Separate pull-up/pull-down output drive pins • Matched delay outputs • Under voltage lockout with hysteresis band
IR21141SS Connection Diagram
IR21141SSPBF Parameters
Technical/Catalog Information
IR21141SSPBF
Vendor
International Rectifier
Category
Integrated Circuits (ICs)
Configuration
Half Bridge
Voltage - Supply
11.5 V ~ 20 V
Current - Peak
2A
Delay Time
440ns
Package / Case
24-SSOP
Packaging
Tube
Number of Outputs
2
Input Type
Non-Inverting
Number of Configurations
1
Operating Temperature
-40°C ~ 125°C
High Side Voltage - Max (Bootstrap)
600V
Drawing Number
*
Lead Free Status
Lead Free
RoHS Status
RoHS Compliant
Other Names
IR21141SSPBF IR21141SSPBF
IR21141SSPBF General Description
The IR211(4,41)/IR221(4,41) gate driver family is suited to drive a single half bridge in power switching applications. These drivers provide high gate driving capability (2 A source, 3 A sink) and require low quiescent current, which allows the use of bootstrap power supply techniques in medium power systems. These drivers feature full short circuit protection by means of power transistor desaturation detection and manage all half-bridge faults by smoothly turning off the desaturated transistor through the dedicated soft shutdown pin, therefore preventing over-voltages and reducing EM emissions. In multi-phase systems, the IR211(4,41)/ IR221(4,41) drivers communicate using a dedicated local network (123456789SY_FLT and 123456789FAULT/SD signals) to properly manage phase-to-phase short circuits. The system controller may force shutdown or read device fault state through the 3.3 V compatible CMOS I/O pin (123456789FAULT/SD). To improve the signal immunity from DC-bus noise, the control and power ground use dedicated pins enabling low-side emitter current sensing as well. Undervoltage conditions in floating and low voltage circuits are managed independently.
IR21141SSPBF Maximum Ratings
Symbol
Definition
Min.
Max.
Units
VS
High side offset voltage
VB - 25
VB + 0.3
V
VB
High side floating supply voltage
(IR2114 or IR21141)
-0.3
625
V
(IR2214 or IR22141)
-0.3
1225
V
VHO VCC COM VLO VIN
High side floating output voltage (HOP,HON and SSDH) Low side and logic fixed supply voltage Power ground Low side output voltage (LOP, LON and SSDL) Logic input voltage (HIN, LIN and FLT_CLR)
VS- 0.3 -0.3 VCC- 25 VCOM-0.3 VSS -0.3
VB + 0.3 25 VCC + 0.3 VCC + 0.3 VCC + 0.3
V V V V V
VFLT
FAULT input/output voltage (FAULT/SD and SY_FLT)
VSS-0.3
VCC + 0.3
V
VDSH VDSL
High side DS input voltage Low side DS input voltage
VS -3 VCOM -3
VB + 0.3 VCC + 0.3
V V
dVs/dt PD RthJA
Allowable offset voltage slew rate Package power dissipation @ TA 25 Thermal resistance, junction to ambient
- - -
50 1.5 65
V/ns W /W
TJ TS TL
Junction temperature Storage temperature Lead temperature (soldering, 10 seconds)
- -55 -
150 150 300
IR21141SSPBF Features
·Floating channel up to +600 V or +1200 V ·Soft over-current shutdown ·Synchronization signal to synchronize shutdown with the other phases ·Integrated desaturation detection circuit ·Two stage turn on output for di/dt control ·Separate pull-up/pull-down output drive pins ·Matched delay outputs ·Undervoltage lockout with hysteresis band ·LEAD-FREE
