RFD16N06LESM, RFD16N06LESM9A, RFD16N06LFSM

Table of contents:
Info of RFD16N06LESM
Info of RFD16N06LESM9A
Info of RFD16N06LFSM

RFD16N06LESM, RFD16N06LESM9A, RFD16N06LFSM Selling Leads, Datasheet

MFG:Fairchild Semiconductor (VA) Category:Discrete Semiconductor Products Package Cooled:TO-252 D/C:TO

RFD16N06LESM, RFD16N06LESM9A, RFD16N06LFSM Datasheet download

Five Points

Part Number: RFD16N06LESM9A

Category: Discrete Semiconductor Products

MFG: Fairchild Semiconductor (VA)

Package Cooled: TO-252

D/C: TO

Description: MOSFET N-CHAN 60V 16A TO-252AA

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

RFD16N06LESM General Description

These are N-Channel power MOSFETs manufactured using a modern process. This process, which uses feature sizes approaching those of LSI integrated circuits gives optimum utilization of silicon, resulting in outstanding performance. They were designed for use in applications such as switching regulators, switching converters, motor drivers, relay drivers and emitter switches for bipolar transistors. This performance is accomplished through a special gate oxide design which provides full rated conductance at gate bias in the 3V to 5V range, thereby facilitating true on-off power control directly from logic level (5V) integrated circuits

RFD16N06LESM Maximum Ratings

	RFD16N06LESM	UNITS
Drain to Source Voltage (Note 1) V_DSS	60	V
Drain to Gate Voltage (RGS = 1MW) (Note 1)V_DGR	60	V
Continuous (Figure 2)ID	16	A
Pulsed Drain Current (Note 3) I_DM	Refer to Peak Current Curve	A
Gate to Source Voltage V_GS	+10, -8	V
Pulsed Drain Current IDM	Refer to UIS Curve	W
Power Dissipation	90	W
Derate above 25oC	0.606	A
Pulsed Avalanche Rating UIS	Refer to UIS SOA
Operating and Storage Temperature .TJ, T^STG	-55 to 75	^o C
Maximum Temperature for Soldering
Leads at 0.063in (1.6mm) from Case for 10s TL	300	^oC
Package Body for 10s, See Techbrief 334 Tpkg	260	^oC

RFD16N06LESM Features

• 16A, 60V
• rDS(ON) = 0.047Ω
• Temperature Compensating PSPICE® Model
• Can be Driven Directly from CMOS, NMOS, TTL Circuits
• Peak Current vs Pulse Width Curve
• UIS Rating Curve
• Related Literature - TB334 "Guidelines for Soldering Surface Mount Components to PC Boards"

RFD16N06LESM9A Parameters

Technical/Catalog Information	RFD16N06LESM9A
Vendor	Fairchild Semiconductor (VA)
Category	Discrete Semiconductor Products
Mounting Type	Surface Mount
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25° C	16A
Rds On (Max) @ Id, Vgs	47 mOhm @ 16A, 5V
Input Capacitance (Ciss) @ Vds	1350pF @ 25V
Power - Max	90W
Packaging	Digi-Reel?
Gate Charge (Qg) @ Vgs	62nC @ 10V
Package / Case	DPak, SC-63, TO-252 (2 leads+tab)
FET Feature	Logic Level Gate
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	RFD16N06LESM9A RFD16N06LESM9A RFD16N06LESM9ADKR ND RFD16N06LESM9ADKRND RFD16N06LESM9ADKR
