PDF/DataSheet Download
Datasheet: S6500
File Size: 504425 KB
Manufacturer: AUK [AUK corp]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: S6500P
File Size: 525396 KB
Manufacturer: AUK [AUK corp]
Download : Click here to Download
PDF/DataSheet Download
Datasheet: S6510
File Size: 323886 KB
Manufacturer: AUK [AUK corp]
Download : Click here to Download
This device is power factor correction controller using a discontinues conduction mode of boost converter. Especially, it is optimized for electronic ballasts which prevent abnormal functions in load runaway and feedback loop fault conditions and low power and high density power supplies which require minimum board size. |
CHARACTERISTICS |
SYMBOL |
VALUE |
UNITS |
Supply Voltage |
VCC |
18 |
V |
Supply voltage Regulator Maximum Current |
ICC(max) |
35 |
mA |
Peak Drive Output Current |
Ioh, lol |
±500 |
mA |
Driver Output Clamping Diodes Vo>Vcc or Vo<-0.3V |
Iclamp |
±10 |
mA |
Detect Clamping Diodes |
ldet |
±10 |
mA |
Error Amp, Compensation and Multiplier Input Voltage |
Vin |
-0.3 to 6 |
V |
Power Dissipation @ Pamb=50 |
Pd |
0.65 |
W |
This device is power factor correction controller using a discontinues conduction mode of boost converter. Especially, it is optimized for electronic ballasts which prevent abnormal functions in load runaway and feedback loop fault conditions and low power and high density power supplies which require minimum board size. The external component R/C filter is not necessary because the R/C filter is included in current sense block. This is the improved version with a pin out equivalent to world standard.
CHARACTERISTICS |
SYMBOL |
VALUE |
UNITS |
Supply Voltage |
VCC |
18 |
V |
Supply voltage Regulator Maximum Current |
ICC( max) |
35 |
mA |
Peak Drive Output Current |
Ioh, lol |
±500 |
mA |
Driver Output Clamping Diodes Vo>Vcc or Vo<-0.3V |
Iclamp |
±10 |
mA |
Detect Clamping Diodes |
ldet |
±10 |
mA |
Error Amp, Compensation and Multiplier Input Voltage |
Vin |
-0.3 to 6 |
V |
Power Dissipation @ Pamb=50 |
Pd |
0.8 |
W |
The device provides simple and performance electronics ballast control function for the half bridge L/C resonant inverter. This device is optimized for electronics ballast requiring a minimum board area, reduced component count and low power dissipation. |
CHARACTERISTICS |
SYMBOL |
VALUE |
UNITS |
Supply Voltage |
VCC |
18 |
V |
Peak Drive Output Current |
Ioh, lol |
±400 |
mA |
Driver Output Clamping Diodes Vo>Vcc or Vo<-0.3V |
Iclamp |
±10 |
mA |
Error Amp, Compensation and Multiplier Input Voltage |
Vin |
-0.3 to 6 |
V |
Power Dissipation @ Pamb=50 |
Pd |
0.8 |
W |
