The circuit includes Hall generator, amplifier and Schmitt-Trigger on one chip. Theinternal reference provides the supply voltage for the components. A magnetic fieldperpendicular to the chip surface induces a voltage at the hall probe. This voltage isamplified and switches a Schmitt-trigger with open-collector output. A protection diodeagainst reverse power supply is integrated. The output is protected against electrical disturbances.
TLE4935L Maximum Ratings
Parameter
Symbol
Limit Values
Unit
Remarks
min.
max.
Supply voltage
VS
40
32
V
Supply voltage
VS
40
V
t < 400 ms; n = 0.1
Output voltage
VQ
32
V
Output current
IQ
100
mA
Output reverse current
IQ
100
mA
Junction temperature
Tj
40
150
°C
Junction temperature
Tj
170
°C
1000 h
Junction temperature
Tj
210
°C
40 h
Storage temperature
Tstg
60
150
°C
Thermal resistance
RthJA
190
K/W
TLE4935L Features
Features • Temperature compensated magnetic performance • Digital output signal • For unipolar and alternating magnetic fields • Large temperature range • Protection against reversed polarity • Output protection against electrical disturbances
