12TTS08

On-State RMS Current (It RMS) :
Mounting Style : Through Hole
Packaging : Tube
Gate Trigger Voltage (Vgt) : 1 V
Rated Repetitive Off-State Voltage VDRM : 800 V
Gate Trigger Current (Igt) : 15 mA
Maximum Gate Peak Inverse Voltage : 10 V
Holding Current (Ih Max) : 30 mA
Off-State Leakage Current @ VDRM IDRM : 0.05 mA
Breakover Current IBO Max : 140 A
Forward Voltage Drop : 1.2 V
Package / Case : TO-220AC


Application




Specifications




Description

The 12TTS08 SAFEIR series of silicon controlled rectifiers are specifically designed for medium power switching and phase control applications. The glass passivation technology used has reliable operation up to 125° C junction  temperature.

Typical applications are in input rectification and crow-bar (soft start) and these products are designed to be used with International Rectifier input diodes, switches and output rectifiers which are available in identical package outlines.
