DescriptionThe 1319 is a OC-192/STM-64 lightwave receiver.
Features of the 1319 are:(1)high data rate capability:10Gbits/s;(2)APD or PIN photodetector;(3)fully operational through the 1.3m to 1.55m wavelength range;(4)typical sensitivity:with pin..-18dBm,with APD..-26dBm;(5)23dB typical dynamic range;(6)single-mode fiber pigtail with FC/PC or SC optial connector;(7)operating case temperature range:0 to 65;(8)50 ac-coupled data output;(9)compact butterfly package with precision microwave K connector* for data output.
The absolute maximum ratings of the 1319 can be summarized as:(1)supply voltage:positive supply,VCC..0V to 5.8Vnegative supply,VEE..0V to -5.8V;(2)photodiode supply current:forward*..20mAreverse..2mA;(3)optical input power:APD(PMAX)..2dBmPIN(PMAX)..5dBm;(4)operatin case temperature,TC:0 to 65;(5)storage temperature,TC:-40 to 85;(6)lead soldering temperature:250;(7)lead soldering time:10s.*device is normally reversed biased,forward biasing the photodiode may compromise device performance and reliability.under biased conditions.undiased,the maximum input optical power for both devices is +8 dBm.
If you want to know more information such as the electrical characteristics about the 1319, please download the datasheet in www.seekic.com or www.chinaicmart.com .
Parameters: | Technical/Catalog Information | 1319 |
| Vendor | Paladin Tools |
| Category | Tools |
| Tool Type | RF, Coax Hex Crimp |
| For Use With/Related Products | N Connector, Wire Size RG8, 11, 213, 216 |
| Features | Side Entry |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | 1319
