1517-200G

Features:

5 taps of equal delay increment
Delays as large as 300ns available
Low DC resistance
Standard 14-pin DIP package
Epoxy encapsulated
Meets or exceeds MIL-D-23859C



Pinout




Description

The 1517-200G device is a fixed, single-input, five-output, passive delay line.  The signal input (I_N) is reproduced at the outputs (T1-T5) in equal
increments.  The delay from IN to T5 (T_D) is given by the device dash number.  The characteristic impedance of the 1517-200G is given by the letter code that follows the dash number (See Table).  The rise time (T_R) of the 1517-200G is 33% of T_D, and the 3dB bandwidth is given by 1.05 / T_D.
