15TQ060S

Recovery Time :
Maximum Power Dissipation :
Configuration : Single
Mounting Style : SMD/SMT
Product : Schottky Rectifiers
Packaging : Tube
Operating Temperature Range : - 55 C to + 150 C
Forward Continuous Current : 15 A
Peak Reverse Voltage : 60 V
Package / Case : D2PAK (TO-263AB)
Max Surge Current : 1000 A
Forward Voltage Drop : 0.82 V at 30 A
Maximum Reverse Leakage Current : 800 uA


Application

150° CT_J operation
High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance
Very low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term reliability




Specifications

Description

The 15TQ060 Schottky rectifier has been optimized for very ow forward voltage drop, with moderate leakage. The proprie- ary barrier technology allows for reliable operation up to 150°C junction temperature. Typical applications of the 15TQ060 are in switching power supplies, converters, free-wheeling diodes, and everse battery protection.

Schottky Rectifier, 15 A
