183NQ

Features:

175° C T_j operation
Unique high power, Half-Pak module
Replaces three parallel DO-5's
Easier to mount and lower profile than DO-5's
High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance
Low forward voltage drop
High frequency operation
Guard ring for enhanced ruggedness and long term reliability


Specifications




Description

The 183NQ high current Schottky rectifier module series has been optimized for low reverse leakage at high temperature.
The proprietary barrier technology allows for reliable operation up to 175° C junction temperature. Typical applications of 183NQ are in switching power supplies, converters, free-wheeling diodes, and reverse battery protection.
