1R5DL41

Features of the 1R5DL41 are:(1)repetitive peak reverse voltage:VRRM=200V;(2)average forward current:IF(AV)=1.5A(Ta=25);(3)very fast reverse-recovery time:trr=60ns(Max.);(4)The low forward voltage of the 1R5DL41:VFM=0.98V(Max.);(5)available to reduce switching losses and output noise.

The maximum ratings of the 1R5DL41 can be summarized as:(1):the characteristic is repetitive peak reverse voltage,the symbol is VRRM,the rating is 200,the unit is V;(2):the characteristic is average forward current(Ta=25),the symbol is IF(AV),the rating is 1.5,the unit is A;(3):the characteristic is peak one cycle surge forward current (non-repetitive),the symbol is IFSM,the rating is 60(50Hz),the unit is A;(4)the characteristic of the 1R5DL41 is junction temperature,the symbol is Tj,the rating is -40 to 150,the unit is ;(5):the characteristic of the 1R5DL41 is storage temperature range,the symbol is Tstg,the rating is -40 to 150,the unit is .

The electrical characteristics of the 1R5DL41 can be summarized as:(1):the characteristic of the 1R5DL41 is peak forward voltage,the symbol is VFM,the Max is 0.98,the unit is V;(2):the characteristic is repetitive peak reverse current,the symbol is IRRM,the Max is 100,the unit is A;(3):the characteristic of the 1R5DL41 is reverse recovery time,the symbol is trr,the Max is 60,the unit is ns;(4):the characteristic of the 1R5DL41 is forward recovery time,the symbol is tfr,the Max is 100,the unit is ns;(5):the characteristic is thermal resistance,the symbol is Rth(j-a),the Max is 100,the unit is /W;(6):the characteristic is thermal resistance,the symbol is Rth(j-e),the Max is 30,the unit is /W.
