Purchase 1T362, In-stock 1T362 From SeekIC.
Package Cooled:323
Part Number: 1T362
Package Cooled: 323
Description: The 1T362 is a variable capacitance diode designed for electronic tuning of TV tuners, and the super miniature package ...
- Table of contents:
1T362
-
Suppliers
DataSheet
General Description
1T362 General Description
The 1T362 is a variable capacitance diode designed for electronic tuning of TV tuners, and the super miniature package allows the tuner miniaturization.
1T362 Maximum Ratings
• Reverse voltage VR 30 V
• Peak reverse voltage VRM 35 V
(RL³10 k)
• Operating temperature Topr 85 °C
• Storage temperature Tstg 55 to +150 °C
• Peak reverse voltage VRM 35 V
(RL³10 k)
• Operating temperature Topr 85 °C
• Storage temperature Tstg 55 to +150 °C
1T362 Features
• Super miniature package
• Low series resistance 0.65 Max. (f=470 MHz)
• Large capacitance ratio 6.5 Typ. (C2/C25)
• Small leakage current 10 nA Max. (VR=28 V)
• Maximum capacitance deviation
3 % Max.
• Low series resistance 0.65 Max. (f=470 MHz)
• Large capacitance ratio 6.5 Typ. (C2/C25)
• Small leakage current 10 nA Max. (VR=28 V)
• Maximum capacitance deviation
3 % Max.
1T362 Typical Application
Electronic tuning for TV and CATV
