Purchase 2021-200, In-stock 2021-200 From SeekIC.
Part Number: 2021-200
Description: The 2020- and 2021-series devices are fixed, single-input, single-output,passive delay lines. The sign...
- Table of contents:
2021-200
-
Suppliers
DataSheet
General Description
2021-200 General Description
The 2020- and 2021-series devices are fixed, single-input, single-output,passive delay lines. The signal input (IN) is reproduced at the output (OUT), shifted by a time (TD) given by the device dash number. The characteristic impedance of the lines is nominally 50 ohms. The rise time (TR) of the lines is no more than 1ns, resulting in a 3dB bandwidth of at least 350MHz.
2021-200 Maximum Ratings
· Tolerance: 2% or 10ps
· Bandwidth: >350MHz
· Ripple in pass-band: Approx. 0.2dB
· Dielectric breakdown: >500 Vdc
· Operating temperature: -65°C to +125°C
· Temperature coefficient: <100 PPM/°C
· Bandwidth: >350MHz
· Ripple in pass-band: Approx. 0.2dB
· Dielectric breakdown: >500 Vdc
· Operating temperature: -65°C to +125°C
· Temperature coefficient: <100 PPM/°C
2021-200 Features
· Microstrip Technology
· Fast rise time for high frequency applications
· Delay available from 100ps to 2500ps
· Very narrow device (SIP package)
· Stackable for PC board economy
· Epoxy encapsulated
· Meets or exceeds MIL-D-23859C
· Fast rise time for high frequency applications
· Delay available from 100ps to 2500ps
· Very narrow device (SIP package)
· Stackable for PC board economy
· Epoxy encapsulated
· Meets or exceeds MIL-D-23859C
2021-200 Connection Diagram
