The CXG1213XR can be used in wireless communication systems, for example, W-CDMA handsets. The features of CXG1213XR are: (1)Low insertion loss; (2)2 CMOS compatible control.

The following is about the absolute maximum ratings of CXG1213XR: (1)Bias voltage: 7 V; (2)Control voltage: 5 V; (3)Operating temperature: -35 to +85 ; (4)Storage temperature: -65 to +150 .

The electrical characteristics of the CXG1213XR are: (1)VSWR: 1.2; (2)Switching speed TSW: 5 to 10 s; (3)1dB compression input power P1dB: 32 dBm at VDD = 2.85V; (4)ACLR: ACLR1: 60 to 50 dBc at ±5MHz, 3.84MHz BW*1, ACLR2: 65 to 55 dBc at ±10MHz, 3.84MHz BW*1 ; (5)Harmonics: 2fo: 95 to 80 dBc, 3fo: 90 to 75 dBc; (6)Bias current IDD: 80 to 150 A at VDD = 2.85V; (7)Control current Ictl: 10 to 20 A at Vctl (H) = 1.85V.
