22-05-7035

22- Series Datasheet download

Five Points

Part Number: 22-05-7035

Category: Connectors

MFG: Molex Connector Corporation





Descriptions: CONN HEADER 3POS 2.5MM R/A TIN

Price Break

1
10
100
500
1000

Unit Price

.90000
.79600
.53080
.42460
.35242

Extended Price

0.90
7.96
53.08
212.30
352.42

(All prices are in USD) Prices for reference only
Urgent Purchase

22-05-7035 General Description

CONN HEADER 3POS 2.5MM R/A TIN

22-05-7035 Parameters

Technical/Catalog Information22-05-7035
VendorMolex Connector Corporation
CategoryConnectors
ColorNatural
Connector TypeHeader, Shrouded
Contact FinishTin
Contact Mating Length0.138" (3.50mm)
Features-
Mounting TypeThrough Hole, Right Angle
Number of Contacts LoadedAll
Number of Rows1
Pitch0.098" (2.50mm)
Row Spacing-
PackagingBulk
Fastening Type-
TerminationSolder
Contact Finish Thickness160in (4.06m)
Number of Positions 3
Contact TypeMale Pin
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names 22 05 7035
22057035
WM18901 ND
WM18901ND
WM18901
