237 Series

The 237 Series is designed to provide more aggressive performance than the 220 or 221 series. The series has much higher common mode and differential mode filtering. The low leakage current makes this a very attractive filter for general filtering of all electronic power systems. And the electrical characteristics of 237 Series can be summarized as:(1)Operating voltage = 115/250 Vac; (2)Operating current = 1, 2, 3, 5, 10 Amp; (3)Operating frequency = 50/60Hz; (4)Operating temperature = -20 to 50 o C; (5)Diel. withstanding (line - case) = 1500 Vac; (6)Diel. withstanding (line - line) = 1500 Vdc; (7)Leakage current = 0.5 ma at 250 Vac, 60 Hz; (8)Max residual voltage after 1 sec. = 30 Volts; (9)Agency approvals = UL, CSA. If you want to know more information about the 237 Series, please download the datasheet in www.seekic.com or www.chinaicmart.com .
