Product Details

Description



Features:

·With the adoption of frequency-writing technology, even the tightest delivery deadline can be met.
·Two frequencies: switch from one to the other according to the input voltage (high or low) of PAD #1.
·PLL technology allows this crystal oscillator to support 1 to 125 MHz.
·Automatic mounting by taping and IR reflow (lead-free) are possible.
·Compact and light with the following dimensions and weight of 5.0 x 3.2 mm,1.0 mm, and 0.06 g.


Application

For compact mobile information equipment, such as PDA and notebook PC


Specifications

Item
Model
2795V
Output level
Frequency range *1
Operating temperature range *2
Frequency stability
Power supply voltage
Consumption current (+5.0V,25) max
VOL max/VOH min
Tr max/Tf max
Duty Cycle min. to max.
Load (CL) max
Oscillation start time max
Number for specifying an order		 (MHz)
()
(*106)
(V)
(mA)
(V)
(ns)
(%)
TTL GATE
(ms)		 TTL
1 F 40 40 < F 70 70 < F 125
20 to +70
±100
+5.0±0.5
25 40 50
0.4V/2.4V IOL=8mA IOH=8mA
2.5/2.5 (0.4V to 2.4V)
40 to 60 (at 1.4V)
5
10
NSA5334A
