2807A

Features: • Only PIN photodiode required as an external component.• Following carrier frequencies (fO) selectable (five types): PC2807 : fO = 32.7, 36.0, 36.7, 37.9 kHz PC2807A : fO = 40.0 kHz• Fixed trap frequencyfT = 54 kHz• Active-low output• Supplied in form of wa...

product image

2807A Picture
See larger image
SeekIC No. : 004218017 Detail

2807A: Features: • Only PIN photodiode required as an external component.• Following carrier frequencies (fO) selectable (five types): PC2807 : fO = 32.7, 36.0, 36.7, 37.9 kHz PC2807A : fO = 40...

2807A Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
2807A
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Only PIN photodiode required as an external component.
• Following carrier frequencies (fO) selectable (five types):
PC2807 : fO = 32.7, 36.0, 36.7, 37.9 kHz
PC2807A : fO = 40.0 kHz
• Fixed trap frequency
fT = 54 kHz
• Active-low output
• Supplied in form of wafer


Application

• Receiver module of infrared remote controller


Specifications

Parameter
Symbol
Ratings
Unit
Supply voltage
VCC
5.5
V
Output sink current
IOSINK
2.5
mA
Input voltage
VIN
0 to VCC
V
Storage temperature
Tstg
−40 to +125
°C
Caution Product quality may suffer if the absolute maximum rating is exceeded even momentarily for any
parameter. That is, the absolute maximum ratings are rated values at which the product is on the verge
of suffering physical damage, and therefore the product must be used under conditions that ensure
that the absolute maximum ratings are not exceeded.


Description

The PC2807 and 2807A are semiconductors integrated circuit developed as preamplifiers for the receiver module of infrared remote controllers. These preamplifiers can be directly connected to a PIN photodiode, and integrate a high-gain first stage amplifier, limiter, bandpass filter, detector circuit, and waveform-shaping circuit on a single chip.
