29LV160T-90PFTN

The 29LV160T-90PFTN is a 16M-bit, 3.0 V-only Flash memory organized as 2M bytes of 8 bits each or 1M words of 16 bits each. The features of 29LV160T-90PFTN are: (1)Single 3.0 V read, program and erase; (2)Compatible with JEDEC-standard commands; (3)Compatible with JEDEC-standard world-wide pinouts; (4)Minimum 100,000 program/erase cycles; (5)High performance; (6)Sector erase architecture; (7)Boot Code Sector Architecture; (8)Embedded EraseTM Algorithms.

The following is about the absolute maximum ratings of 29LV160T-90PFTN: (1)Storage Temperature: 55°C to +125°C; (2)Ambient Temperature with Power Applied: 40°C to +85°C; (3)Voltage with respect to Ground All pins except A9, OE, and RESET: 0.5 V to +VCC +0.5 V; (4)VCC: 0.5 V to +5.5 V; (5)A9, OE, and RESET: 0.5 V to +13.0 V.

The electrical characteristics of the 29LV160T-90PFTN are: (1)Input Leakage Current: 1.0 A min and +1.0 A max at VIN = VSS to VCC, VCC = VCC Max.; (2)Output Leakage Current: 1.0 A min and +1.0 A max at VOUT = VSS to VCC, VCC = VCC Max. ; (3)A9, OE, RESET Inputs Leakage Current: 35 A max at VCC = VCC Max., A9, OE, RESET = 12.5 V; (4)VCC Active Current: 35mA max at CE = VIL, OE = VIH; (5)VCC Current (Standby): 5 A at VCC = VCC Max., CE = VCC ±0.3 V, RESET = VCC ±0.3 V; (6)VCC Current (Standby, RESET): 5 A max at VCC = VCC Max.,; (7)RESET = VSS ±0.3 V.
