2DD2652-7, US $ .06-.25 , Diodes Inc., 2DD2652-7 DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 00206281 Detail

2DD2652-7: Transistors Bipolar (BJT) LOW VSAT NPN SMT 3K

2DD2652-7 Data Sheet

US $ .06~.25 / Piece | Get Latest Price

Part Number:: 2DD2652-7
Mfg:: Diodes Inc.
Supply Ability:: 5000

Price Break

Qty
0~1
1~10
10~100
100~250

Unit Price
$.25
$.18
$.09
$.06

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/28

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

2DD2661 evaluate
Specifications Part Number 2DD2661 Product Type NPN VCEO(V) 12 IC (A) 2 ICM ...
2DD2678 evaluate
Specifications Part Number 2DD2678 Product Type NPN VCEO(V) 12 IC (A) 3 ICM ...
2DD2679 evaluate
Specifications Part Number 2DD2679 Product Type NPN VCEO (V) 30 IC(A) 2 ICM ...

Product Details

Quick Details

Transistor Polarity :	NPN	Collector- Emitter Voltage VCEO Max :	12 V
Emitter- Base Voltage VEBO :	6 V	Maximum DC Collector Current :	1.5 A
Configuration :	Single	Maximum Operating Frequency :	260 MHz
Maximum Operating Temperature :	+ 150 C	Mounting Style :	SMD/SMT
Package / Case :	SOT-323	Packaging :	Reel

Description

DC Collector/Base Gain hfe Min :
Transistor Polarity : NPN
Configuration : Single
Maximum Operating Temperature : + 150 C
Mounting Style : SMD/SMT
Packaging : Reel
Emitter- Base Voltage VEBO : 6 V
Collector- Emitter Voltage VCEO Max : 12 V
Package / Case : SOT-323
Maximum DC Collector Current : 1.5 A
Maximum Operating Frequency : 260 MHz

Parameters:

Technical/Catalog Information	2DD2652-7
Vendor	Diodes Inc
Category	Discrete Semiconductor Products
Transistor Type	NPN
Voltage - Collector Emitter Breakdown (Max)	12V
Current - Collector (Ic) (Max)	1.5A
Power - Max	300mW
DC Current Gain (hFE) (Min) @ Ic, Vce	270 @ 200mA, 2V
Vce Saturation (Max) @ Ib, Ic	200mV @ 25mA, 500mA
Frequency - Transition	260MHz
Current - Collector Cutoff (Max)	-
Mounting Type	Surface Mount
Package / Case	SOT-323
Packaging	Tape & Reel (TR)
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	2DD2652 7 2DD26527 2DD2652DITR ND 2DD2652DITRND 2DD2652DITR
