2N4126 Product Image

2N4 Series Datasheet download

Five Points

Part Number: 2N4126





Package Cooled: NS





Urgent Purchase

2N4126 Maximum Ratings

Item Symbol Ratings Unit
Collector to base voltage -VCBO 25 V
Collector to base voltage -VCEO 25 V
Emitter to base voltage -VEBO 4 V
Collector current -IC 200 A
Collector peak current -ICM 800 A
Base Current -IB 50 m
Power Dissipation at Tamb = 25 °C Ptot 6251)
Junction temperature Tj 150 °C
Storage temperature Ts 55 to +150 °C
1) Valid provided that leads are kept at ambient temperature at a distance of 2 mm from case.

2N4126 Features

·PNP Silicon Epitaxial Transistor
·for switching and amplifier applications.
·Especially suit-able for AF-driver and
·low-power output stages.
·As complementary type, the NPN transistor
·2N4124 is recommended.
