2SA1768

Features: · Adoption of MBIT process.· High breakdown voltage, large current capacity.· Fast switching speed.Application· Color TV sound output, converter, inverter.PinoutSpecifications Parameter Symbol Conditions Ratings Unit Collector-base voltage VCBO ()180 V Col...

product image

2SA1768 Picture
See larger image
SeekIC No. : 004220241 Detail

2SA1768: Features: · Adoption of MBIT process.· High breakdown voltage, large current capacity.· Fast switching speed.Application· Color TV sound output, converter, inverter.PinoutSpecifications Paramet...

2SA1768 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
2SA1768
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/4

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Adoption of MBIT process.
· High breakdown voltage, large current capacity.
· Fast switching speed.




Application

· Color TV sound output, converter, inverter.




Pinout






Specifications

Parameter
Symbol
 Conditions
Ratings
Unit
Collector-base voltage
VCBO
()180
V
Collector-emitter voltage
VCEO
()160
V
Emitter-base voltage
VEBO
()6
V
Collector current
Ic
()0.7
mA
Collector Current (Pulse)
ICP
()1.5
mA
Collector Dissipation
PC
1
W
Junction temperature
Tj
150
°C
Storage temperature
Tstg
-55 to +150
°C


Absolute maximum ratings
VCBO [V] 180
VCEO [V] 160
IC [A] 0.7
PC [W] 1
Electrical characteristics
hFE min 100
hFE max 400
VCE [V] 5
IC [mA] 100
fT typ [MHz] 120
VCE [V] 10
IC [mA] 50
VCE (sat) typ [V] 0.2
VCE (sat) max [V] 0.5
IC [mA] 250
IB [mA] 25
