2SA2205

Features: • Adoption of FBET, MBIT processes.• Large current capacitance.• Low collector-to-emitter saturation voltage.• High-speed switching.• High allowable power dissipationApplication• DC / DC converter, Relay drivers, lamp drivers, motor driversPinoutSpecif...

product image

2SA2205 Picture
See larger image
SeekIC No. : 004220483 Detail

2SA2205: Features: • Adoption of FBET, MBIT processes.• Large current capacitance.• Low collector-to-emitter saturation voltage.• High-speed switching.• High allowable power dis...

2SA2205 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
2SA2205
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/3

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Adoption of FBET, MBIT processes.
• Large current capacitance.
• Low collector-to-emitter saturation voltage.
• High-speed switching.
• High allowable power dissipation




Application

• DC / DC converter, Relay drivers, lamp drivers, motor drivers




Pinout






Specifications

Absolute maximum ratings
VCEO [V] 100
IC [A] 2
PC [W] 15
Tc=25°C
Electrical characteristics
hFE min 200
hFE max 400
VCE [V] 5
IC [A] 0.1
VCE (sat) typ [V] 0.12
VCE (sat) max [V] 0.24
IC [A] 1
IB [mA] 100


Parameter
Symbol
Conditions
Rating
Unit

Collector-base voltage
Collector-to-Emitter Voltage
Collector-emitter voltage
Emitter-base voltage
Collector current (DC)
Collector current (Pulse)
Base current (DC)
Collector power dissipation

Junction temperature
Storage temperature

VCBO
VCES
VCEO
VEBO
IC
ICP
IB
PC

Tj
Tstg










Tc=25
-100
-100
-100
-7
-2
-3
-400
0.8
15
150
-55 to +150
V
V
V
V
A
A
mA
W
W
°C
°C
