2SC4075

Features: · Highly resistant to breakdown and wide ASO.· Micaless package facilitating mounting.Application· Color TV chroma output, sound output and B/W TV video output, audio output applications.PinoutSpecifications Absolute maximum ratings VCEO [V] 300 IC [A] 0.2 PC Tc=2...

product image

2SC4075 Picture
See larger image
SeekIC No. : 004222710 Detail

2SC4075: Features: · Highly resistant to breakdown and wide ASO.· Micaless package facilitating mounting.Application· Color TV chroma output, sound output and B/W TV video output, audio output applications.P...

2SC4075 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
2SC4075
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/12/5

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Highly resistant to breakdown and wide ASO.
· Micaless package facilitating mounting.




Application

· Color TV chroma output, sound output and B/W TV video output, audio output applications.




Pinout






Specifications

Absolute maximum ratings
VCEO [V] 300
IC [A] 0.2
PC Tc=25°C [W] 10
Electrical characteristics
hFE min 40
hFE max 200
VCE [V] 10
IC [A] 0.01
VCE (sat) max *typ [V] 2
IC [A] 0.05
IB [mA] 5
Cob typ [pF] 5.3
VCB [V] 50


Parameter
Symbol
 Conditions
Ratings
Unit
Collector-base voltage
VCBO
300
V
Collector-emitter voltage
VCEO
300
V
Emitter-base voltage
VEBO
7
V
Collector current
IC
200
mA
Collector current(Pulse)
ICP
700
mA
Collector Dissipation
PC
2
W
Tc=25°C
10
W
Junction temperature
Tj
150
Storage temperature
Tstg
55 to +150
