Purchase 2SD23210RA, In-stock 2SD23210RA From SeekIC.

MFG:Panasonic - SSG (VA)  Category:Discrete Semiconductor Products

2SD23210RA

2SD Series Datasheet download

Five Points

Part Number: 2SD23210RA

Category: Discrete Semiconductor Products

MFG: Panasonic - SSG (VA)





Descriptions: TRANS NPN 20VCEO 5A NS-B1

Price Break

1
10
100
500

Unit Price

.59000
.47200
.35390
.19584

Extended Price

0.59
4.72
35.39
97.92

(All prices are in USD) Prices for reference only
Urgent Purchase

2SD23210RA General Description

TRANS NPN 20VCEO 5A NS-B1

2SD23210RA Parameters

Technical/Catalog Information2SD23210RA
VendorPanasonic - SSG (VA)
CategoryDiscrete Semiconductor Products
Transistor TypeNPN
Voltage - Collector Emitter Breakdown (Max)20V
Current - Collector (Ic) (Max)5A
Power - Max400mW
DC Current Gain (hFE) (Min) @ Ic, Vce340 @ 500mA, 2V
Vce Saturation (Max) @ Ib, Ic1V @ 100mA, 3A
Frequency - Transition150MHz
Current - Collector Cutoff (Max)1A
Mounting TypeThrough Hole
Package / CaseNS-B1
PackagingCut Tape (CT)
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names 2SD23210RA
2SD23210RA
2SD23210RACT ND
2SD23210RACTND
2SD23210RACT
