2SD2670
-
Suppliers
DataSheet
General Description
2SD2670 Maximum Ratings
|
Parameter |
Symbol |
Rating |
Unit |
| Collector-base voltage |
VCBO |
15 |
V |
| Collector-emitter voltage |
VCEO |
12 |
V |
| Emitter-base voltage |
VEBO |
6 |
V |
| Collector current |
IC |
3 |
A |
| Collector current |
ICP |
6 |
A*1 |
| Power dissipation |
PC |
500
|
mW |
|
1*2 |
W | ||
| Junction temperature |
Tj |
150 |
°C |
| Range of storage temperature |
Tstg |
-55to+150 |
°C |
*2 Mounted on a 25×25× t 0.8mm Ceramic substrate
2SD2670 Features
1) A collector current is large.
2) VCE(sat) 250mV
At lc=1.5A / lB=30mA
2) VCE(sat) 250mV
At lc=1.5A / lB=30mA
2SD2670 Typical Application
Low frequency amplifier
Driver
Driver
2SD2670
