The 2SK1541L is a very good product. If you want to use it you must learn about it rightly. Here you can know some features about it. The 2SK1541L has five features. Please pay attention to them. The first feature of the 2SK1541L is low on-resistance, the second feature of the 2SK1541L is low drive current. The third feature of the 2SK1541L is no secondary breakdown, the fourth feature of the 2SK1541L is high speed switching. The fifth feature of the 2SK1541L is that it is suitable for switching regulator, DC-DC converter. The above features are what I want to tell you.
The features of the 2SK1541L make itself have many applications. Here show one application to you. It may make you know how good the 2SK1541L is. It is high speed power switching.
The absolute maximum ratings of the 2SK1541L can make you clear of the 2SK1541L, I am very glad to show you the absolute maximum ratings of the 2SK1541L. it has eight absolute maximum ratings . The first absolute maximum rating is the drain to source voltage which is 500V, and its symbol is VDSS. The second absolute maximum rating is gate to source voltage which is ±30 V, and its symbol is VGSS. The third absolute maximum rating is drain current, which is 7A, and its symbol is ID. The fourth absolute maximum rating is drain peak current, which is 28 A, and its symbol is ID(pulse)*1. The fifth absolute maximum rating is body to drain diode reverse drain current, which is 7A, and its symbol is IDR. The sixth absolute maximum rating is channel dissipation, which is 60W, and the symbol is Pch*2. The seventh absolute maximum rating is channel temperature, which is 150 °C , and its symbol is Tch. The last absolute maximum rating is storage temperature, which range from -55°C to +150°C. You ought to know the whole numbers.
Next I will show you some cautions of the 2SK1541L. The first is that hitachi neither warrants nor grants licenses of any rights of Hitachi's or any third party's patent, copyright, trademark, or other intellectual property rights for information contained in this document. Hitachi bears no responsibility for problems that may arise with third party's rights, including intellectual property rights, in connection with use of the information contained in this document. The second is that products and product specifications may be subject to change without notice. Confirm that you have received the latest product standards or specifications before final design, purchase or use.
If you are willing to find more about the 2SK1541L, please pay attention to our web! Thank you for being concerned of our information.
