Senses Motion of Ferrous Targets Such as Gears
Wide Operating Temperature Range
Operation to 30 kHz
Resistant to RFI, EMI

Large Effective Air Gap
4.5 V to 24 V Operation
Output Compatible With All Logic Families
Reverse Battery Protection
Resistant to Physical Stress

  A gear-tooth sensing system consists of the sensor IC, a back-biasing magnet, and a target. The system requirements are usually specified in terms of the effective working air gap between the package and the target (gearteeth), the number of switching events per rotation of the target, temperature and speed ranges, minimum pulse duration or duty cycle, and switch point accuracy. Careful choice of the sensor IC, magnet material and shape, target material and shape, and assembly techniques enables large working air gaps and high switch-point accuracy over the system operating temperature range.

Supply Voltage, V_CC ............................. ..24 V
Reverse Battery Voltage, V_RCC ............. -30 V
Magnetic Flux Density, B ................. Unlimited
Output OFF Voltage, V_OUT...................... 24 V
Output Current, I_OUT .......................... 25 mA
Package Power Dissipation,
       PD ............................................. 500 mW
Operating Temperature Range, T_A
       Prefix 'UGN' .............. -20°C to +85°C
       Prefix 'UGS' ............ -40°C to +125°C
Storage Temperature Range,
       T_S ............................ .. -65°C to +150°C
