3280

Symmetrical Switch Points

 Resistant to Physical Stress

Superior Temperature Stability

Output Short-Circuit Protection

Operation From Unregulated Supply

Reverse Battery Protection

Solid-State Reliability

Small Size

It is strongly recommended that an external bypass capacitor be connected (in close proximity to the Hall sensor) between the supply and ground of the device to reduce both external noise and noise generated by the chopper-stabilization technique.

The simplest form of magnet that will operate these devices is a ring magnet.  Other methods of operation, such as linear magnets, are possible.  Extensive applications information on magnets and Hall-effect sensors is also available in the Allegro Electronic Data Book AMS-702 or Application Note 27701, or www.allegromicro.com

Supply Voltage, V_CC .............................. 26.5 V
Reverse Battery Voltage, V_RCC................ -30 V
Magnetic Flux Density, B.....................Unlimited
Output Off Voltage, V_OUT.........................  26 V
Continuous Output Current,
      I_OUT...............................  Internally Limited
Reverse Output Current, I_OUT .............  -50 mA
Package Power Dissipation, P_D. See Graph
Junction Temperature, T_J ..................  +170°C
Operating Temperature Range, T_A
      Suffix 'E'................... -40°C to +85°C
      Suffix 'L'................. -40°C to +150°C
Storage Temperature Range,
      T_S ................................. -65°C to +170°C
