Standard LED - Through Hole 10mm LED
363-2SYGD/S530-E2: Standard LED - Through Hole 10mm LED
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Packaging : | Bulk |
363-2SYGD/S530-E2 is a kind of 10.0mm Round Type LED Lamps.The series is specially designed for applications requiring higher brightness. Also,the led lamps are available with different colors, intensities. It has four applications:TV set, Monitor, Telephone and Computer. The material of 363-2SURD/S530-A3 is AlGaInP . The emittied color is super yellow green and the lens color is green diffused.
Its five unquie features will also attract you !The first one is choice of various viewing angles. The second one is that it is available on tape and reel.The third one is that it is reliable and robust.The forth one is Pb free . And the last one is the product itself will remain within RoHS compliant version.Packing Quantity Specification is 250PCS/1Bag,4Bags/1Box and 10Boxes/1Carton.
Then, there are also some absolute Maximum Ratings of 363-2SYGD/S530-E2(Ta = 25) given to you . Forward Current (IF) is 25 mA. Operating Temperature (Topr) is -40 to +85. Storage Temperature (Tstg) is -40 to +100. Soldering Temperature(T=5 sec)(Tsol) is 260 ± 5 . LED Junction Temperature (Tj) is 125 . Power Dissipation (Pd) is 60 mW. Electrostatic Discharge (ESD) is 2000V. Reverse Voltage (VR) is 5V.
At last, there are some notes about this product. Firstly, above specification may be changed without notice. EVERLIGHT will reserve authority on material change for above specification. Secondly, when using this product, please observe the absolute maximum ratings and the instructionsfor using outlined in these specification sheets. EVERLIGHT assumes no responsibility for any damage resulting from use of the product which does not comply with the absolute maximum ratings and the instructions included in these specification.
If you are willing to find more about the 363-2SYGD/S530-E2, please pay attention to our web! Thank you for being concerned of our information.
