Part Number: 3874 Group
Description: The 3874 group is the 8-bit microcomputer based on the 740 family core technology.The 3874 gro...
- Table of contents:
3874 Group
-
Suppliers
DataSheet
General Description
3874 Group General Description
The 3874 group is the 8-bit microcomputer based on the 740 family core technology.
The 3874 group includes data link layer communication control circuit, A-D converters, D-A converter, automatic data transfer serial I/O, UART, and watchdog timer etc.
The various microcomputers in the 3874 group include variations of internal memory size and packaging. For details, refer to the section on part numbering.
For details on availability of microcomputers in the 3874 group, refer to the section on group expansion.
3874 Group Maximum Ratings
|
Symbol |
Parameter |
Conditions |
Ratings |
Unit |
|
VCC |
Power source voltage | All voltages are based on VSS. Output transistors are cut off. |
0.3 to 7.0 |
V |
|
VI |
Input voltage P00P07, P10P17, P20P27, P30P37, P40P47, P50P57, P60P67, P70P77, P80P87, VREF |
0.3 to VCC +0.3 |
V | |
|
VI |
Input voltage RESET, XIN |
0.3 to VCC +0.3 |
V | |
|
VI |
Input voltage P97 |
0.3 to Vcc +0.3 |
V | |
|
IO |
Output voltage P00P07, P10P17, P20P27, P30P37, P40P47, P50P57, P60P67, P70P77, P80P87, XOUT |
0.3 to VCC +0.3 |
V | |
|
PD |
Power Dissipation | Ta = 25 |
500 |
mW |
|
Topr |
Operating temperature |
40 to 85 |
| |
|
Tstg |
Storage temperature |
60 to 150 |
|
3874 Group Features
`Basic machine-language instructions ...................................... 71
`Minimum instruction execution time ................................. 0.32 s
(at 6.4 MHz oscillation frequency, in double-speed mode)
`Memory size
ROM ............................................................... 16 K to 60 K bytes
RAM............................................................... 1024 to 2048 bytes
`Programmable input/output ports ............................................ 72
`Input port .................................................................................... 1
`Interrupts ................................................. 27 sources, 16 vectors
(Interrupt source discrimination register exists, included key input interrupt)
`Timer 1, timer 2, timer 3 ................................................. 8-bit * 3
`Timer X, timer Y............................................................ 16-bit * 2
`Serial I/O1 .................... 8-bit* 1(UART or Clock-synchronized)
`Serial I/O2 ................................... 8-bit * 1(Clock-synchronized)
`Serial I/O3 ...................................................................... 8-bit *1
(Clock-synchronized automatic data transfer/arbitrary bit transfer function available)
`A-D converter ................................................. 8-bit *8 channels
`D-A converter ................................................... 8-bit * 1 channel
`Data link layer communication control circuit ............................ 1
`Clock generating circuit ..................................... Built-in 2 circuits
(connect to external ceramic resonator or quartz-crystal oscillator)
`Watchdog timer ............................................................ 20-bit * 1
`Power source voltage ................................................ 3.0 to 5.5 V
`Power dissipation
In double-speed mode ......................................................90 mW
In high-speed mode ..........................................................60 mW
(at 32 kHz oscillation frequency, at 5 V power source voltage)
In low-speed mode .......................................................... 180 mW
(at 32 kHz oscillation frequency, at 3 V power source voltage)
`Operating temperature range.................................... 40 to 85
(Extended operating temperature version and automotive version)
`Minimum instruction execution time ................................. 0.32 s
(at 6.4 MHz oscillation frequency, in double-speed mode)
`Memory size
ROM ............................................................... 16 K to 60 K bytes
RAM............................................................... 1024 to 2048 bytes
`Programmable input/output ports ............................................ 72
`Input port .................................................................................... 1
`Interrupts ................................................. 27 sources, 16 vectors
(Interrupt source discrimination register exists, included key input interrupt)
`Timer 1, timer 2, timer 3 ................................................. 8-bit * 3
`Timer X, timer Y............................................................ 16-bit * 2
`Serial I/O1 .................... 8-bit* 1(UART or Clock-synchronized)
`Serial I/O2 ................................... 8-bit * 1(Clock-synchronized)
`Serial I/O3 ...................................................................... 8-bit *1
(Clock-synchronized automatic data transfer/arbitrary bit transfer function available)
`A-D converter ................................................. 8-bit *8 channels
`D-A converter ................................................... 8-bit * 1 channel
`Data link layer communication control circuit ............................ 1
`Clock generating circuit ..................................... Built-in 2 circuits
(connect to external ceramic resonator or quartz-crystal oscillator)
`Watchdog timer ............................................................ 20-bit * 1
`Power source voltage ................................................ 3.0 to 5.5 V
`Power dissipation
In double-speed mode ......................................................90 mW
In high-speed mode ..........................................................60 mW
(at 32 kHz oscillation frequency, at 5 V power source voltage)
In low-speed mode .......................................................... 180 mW
(at 32 kHz oscillation frequency, at 3 V power source voltage)
`Operating temperature range.................................... 40 to 85
(Extended operating temperature version and automotive version)
3874 Group Typical Application
Automotive comfort control for audio system, air conditioning etc., automotive body electronics control, household appliances, and other consumer applications, etc.
3874 Group Connection Diagram
3874 Group Relative Products
3874
The 3874 group is the 8-bit microcomputer based on the 740 family core technology.The 3874 group includes data link layer communication control circuit, A-D converters, D-A converter, automatic data transfer serial I/O, UART, and watchdog timer etc.The vario...
3-87346-0
CONN PLUG 60POS DL .100 VERT
38733-6402
CONN BARRIER SINGLE FLAT COVER
3-87230-0
CONN HEADER RT/A 60POS .100 15AU
3-87227-2
CONN HEADER 64DL POS .100 15GOLD
3-87227-0
CONN HEADER VERT 60POS .100 15AU
