42050

Current Rating :
Voltage Rating :
Fuse Size / Group :
Termination Style :
Fuse Type :
Body Material :
Dimensions :
Packaging :
Product :


Features:

* Output Current To 10 Amps
* Output Voltage To 34 V
* Internal Short Circuit Protection
* Custom Output Voltages available




Application

*Designed for use in general purpose applications.
*Military And Hi Rel Industrial Applications Where Hermetically Sealed Product Is Required




Specifications

Output Current - I_OUT.........................................................................................10 A
Power Dissipation @ 25°C Case Temperature - P_D ........................................120 W
Input Voltage - V_IN..............................................................................................40 V
Operating Temperature ............................................................... -55°C to +125°C
Storage Temperature .................................................................65°C to + 150°C




Description

The 42050 series of regulators covers the output voltage range from 5 VDC through 34 VDC. These regulators are fabricated using hybrid techniques. The 42050 series are complete with internal short circuit protection, which includes voltage shutdown and current fold back. The 42050 series regulators are complete and normally do not require any additional components. However, if the regulator is far from the power source a .2 f capacitor on the input is suggested.
