Part Number: 48CTQ060



MFG: TO-220AB

Package Cooled: 7850

D/C: IR

Description: This center tap Schottky rectifier series has been optimized for low reverse leakage at high temperature. The proprieta...


Urgent Purchase

48CTQ060 General Description


This center tap Schottky rectifier series has been optimized for low reverse leakage at high temperature. The proprietary barrier technology allows for reliable operation up to 150°C junction temperature. Typical applications are in switching power supplies, converters, free-wheeling diodes, and reverse battery protection.

48CTQ060 Maximum Ratings

Parameters
 Values
Units
Conditions
IF(AV) Max.Average Forward (Per Device)
      Current * See Fig.5 (Per Device)
20
A
 50% duty cycle @ T = 135C, rectangular wave form
40
IFms Max. Peak One Cycle Non-Repetitive
     Surge Current (Per Leg)* See Fig.7
1000
A
 5s Sine or 3s Rect. pulse Following any rated
load condition and with
rated VRRM applied
260
 10ms Sine or 6ms Rect.pulse
EAS Non-Repetitive Avalanche Energy
      (Per Leg)
13
mJ
 TJ = 25 °C, IAS = 1.50Amps, L = 11.5 mH
IAR Repetitive Avalanche Current
      (Per Leg)
1.50
A
Current decaying linearly to zero in 1 sec
Frequency limited by TJ max. VA = 1.5 x VR typic

48CTQ060 Features

150° C TJ  operation
Center tap configuration
Low forward voltage drop
High purity, high temperature epoxy encapsulation for enhanced mechanical strength and moisture resistance
High frequency operation
Guard ring for enhanced ruggedness and long term reliability
