500 PGP-ST

      The 500 PGP-ST is designed as aluminum capacitors with power general purpose screw terminals and its typical applications included UPS and energy storage in medical or industrial pulse systems.
      500 PGP-ST has four features.The first one is that it would be polarized aluminum electrolytic capacitors, non-solid electrolyte.The second one is tha 500 PGP-ST would have large types, cylindrical aluminum case, insulated with a blue sleeve.The third one is that it would have pressure relief in the sealing disc.The last one is that 500 PGP-ST would ues thr efficient design.That are all the features.
      Some electrical specifications about 500 PGP-ST.The first one is about its Cr which would be rated capacitance at 100 Hz, tolerance ± 20 %.The second one is about its Ir which would be rated RMS ripple current at 100 Hz, 85 °C.The third one is about its Il5 which would be max. leakage current after 5 minutes at UR.The fourth one is baout 500 PGP-ST's ESR which would be max. equivalent series resistance at 100 Hz.The fifth one is about its Z which would be max. impedance at 10 kHz.Something should be noted that unless otherwise specified, all electrical values of 500 PGP-ST in Tables 2 and 3 apply at Tamb = 20 °C, P = 86 to 106 kPa, RH = 45 to 75 %.
      Also some absolute ratings and additional electrical data of 500 PGP-ST have been concluded into several points as follow.The first one is about its Ssurge voltage which would be Us = 1.1 x Ur with condition of >= 400 V versions.The second one is about 500 PGP-ST's reverse voltage which would be Urev 1 V.The third one is about its leakage current which would be IL1 0.006 Cr x Ur + 4 A with condition of after 1 minute at Ur and would be IL5 0.002 Cr x Ur + 4 A with condition of after 5 minutes at Ur.The fourth one is about 500 PGP-ST's Equivalent series inductance (ESL) which would be typ. 16 nH with condition of case D = 50 mm and would be typ. 19 nH with condition of case D = 65 mm and would be typ. 20 nH with condition of case D = 76 mm and would be typ. 20 nH with condition of case D = 90 mm.And so on.For more information please contact us.
