Position: Home > Datasheet list > 506 Series > Index 5 > 506003B01400
Electronica China

Purchase 506003B01400, In-stock 506003B01400 From SeekIC.

MFG:Aavid Thermalloy  Category:Thermal Management

506003B01400 Product Image

506 Series Datasheet download

Five Points

Part Number: 506003B01400

Category: Thermal Management

MFG: Aavid Thermalloy





Descriptions: BOARD LEVEL HEAT SINK

Price Break

1500

Unit Price

1.05140

Extended Price

1577.10

(All prices are in USD) Prices for reference only
Urgent Purchase

506003B01400 General Description

BOARD LEVEL HEAT SINK

506003B01400 Parameters

Technical/Catalog Information506003B01400
VendorAavid Thermalloy
CategoryThermal Management
Attachment MethodBolt On
Height0.375" (9.53mm)
MaterialAluminum
Package CooledTO-3
Power Dissipation @ Temperature Rise16W @ 90°C
Thermal Resistance @ Forced Air Flow5.0°C/W @ 200 LFM
Outline50.80mm x 44.45mm
Thermal Resistance @ Natural-
Lead Free StatusContains Lead
RoHS StatusRoHS Non-Compliant
Other Names 506003B01400
506003B01400
