5066X
-
Suppliers
DataSheet
General Description
5066X Maximum Ratings
| Item | Symbol | Absolute Max imum Ratings | Unit | |||||
| HBG | HPG | HPY | HAY | HAA | HBR | |||
| Power Dissipation | Pd | 125 | 125 | 125 | 125 | 125 | 100 | mW |
| Forward Current | IF | 50 | 50 | 50 | 50 | 50 | 50 | mA |
| Pulse Forward Current 1 |
IFRM | 100 | 100 | 100 | 100 | 100 | 300 | mA |
| Derating (Ta=25 or higher) |
IF | 0.67 | 0.67 | 0.67 | 0.67 | 0.67 | 0.67 | mA/ |
| Reverse Voltage | VR | 4 | 4 | 4 | 4 | 4 | 4 | V |
|
Operating |
Topr | -30~+85 | ||||||
| Storage Temperature |
Tstg | -30~ +100 | ||||||
5066X Features
・Outer Dimension 5 Round shape type
・Operation temperature range.
Storage Temperature :-30~100
Operating Temperature :-30~85
・Leadfree soldering compatible
・RoHS compliant
・Operation temperature range.
Storage Temperature :-30~100
Operating Temperature :-30~85
・Leadfree soldering compatible
・RoHS compliant
