5305H3/5

LED Circuit Board Indicators AMBER/GREEN DIFF

product image

5305H3/5 Picture
SeekIC No. : 0028351 Detail

5305H3/5: LED Circuit Board Indicators AMBER/GREEN DIFF

floor Price/Ceiling Price

US $ .87~1.53 / Piece | Get Latest Price
Part Number:
5305H3/5
Mfg:
Chicago Miniature
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~500
  • Unit Price
  • $1.53
  • $1.22
  • $.97
  • $.87
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/22

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Illumination Color : Yellow Lens Color/Style : Tinted
Wavelength : 635 nm Luminous Intensity : 17.7 mcd
Packaging : Bulk

Description

LED Size :
Mounting Type :
Viewing Angle :
Packaging : Bulk
Lens Color/Style : Tinted
Illumination Color : Yellow
Wavelength : 635 nm
Luminous Intensity : 17.7 mcd


Pinout




Specifications

Part Number: 5305H3/5
Serial Number: 5305H
Emitted color: Yellow/Green
Lens color: White
Lum in min (mcd): 11.7/10.10
Lum in typ (mcd): 17.7/15.3
Rated current (mA): 20
Cont forward current max: 30
Fwd volts type: 2,1
Forward volt max.: 3
Reverse breakdown V: 5
Viewing angle (°): 60
Peak wave length (mA): 635/567
Housing type: UL94V-0
RoHS Status: Yes


Description

CML LED assemblies 5305H3/5 are available in both right angle and vertical package and utilize the CML IT line of high quality LEDs. Parts range in voltage from 2V to 12V and in current from 2mA to 20mA. The UL94V0 housings ensure proper LED alignment.


Parameters:

Technical/Catalog Information5305H3/5
VendorCML Innovative Technologies Inc
CategoryOptoelectronics
ColorAmber, Green
Mounting TypeThrough Hole, Right Angle
ConfigurationSingle
Voltage Rating2.1V Amber, 2.1V Green
Current 10mA
Lens Style/SizeRound, 5mm, T-1 3/4
PackagingBulk
Lens TypeDiffused, White
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names 5305H3 5
5305H35
L205935 ND
L205935ND
L205935
